LightWELD: Handheld Laser Welding



LightWELD Unbeatable Benefits

  • FAST: Up to 4X faster than TIG
  • VERSATILE: Wide range of materials – up to 1/4 in. (6.35 mm)
  • EASY: Optimized presets reduce learning curve
  • CONSISTENT: High-quality, repeatable results
  • FLEXIBLE: Simple and challenging applications
  • PRODUCTIVE: Pre- and post-weld cleaning capability

Laser Welding


High speed, low heat input, and a small HAZ make laser welding thick, thin, reflective materials, and materials with dissimilar thicknesses far less challenging for all skill levels.

LASER PRE-CLEANING


Pre-weld cleaning removes rust and other contaminants from materials and increases weld quality. This is much faster than manual cleaning and uses no chemicals or abrasives.

LASER POST-CLEANING


Post-weld cleaning removes heat discoloration and improves visual finishes without post-weld grinding.

Three LightWeld Models Available:


LightWELD XR

Delivers a higher brightness beam for welding an extended range of materials and thicknesses up to 0.250” (6.35 mm), including reflective materials. Welding and cleaning materials such as titanium and copper are easy with LightWELD XR.



Welding Capacity

Steel: Stainless Steel, Mild Steel, Galvanized Steel up to 6.35 mm (0.250")

Aluminum: Aluminum (3XXX & 5XXX Series) up to 6.35 mm (0.250")

Aluminum: Aluminum (6XXX Series) up to 3.0 mm (0.120")

Titanium & Nickel Alloy: Up to 5.0 mm (0.200")

Copper: Up to 2.0 mm (0.080")

Wobble Welding: Up to 5 mm (0.200") width

Cleaning Scan Width: Up to 15 mm (0.590")

High Frequency Peak Power for Cleaning: 2500 W

Wire Welding Capability: Yes


LightWELD XC

LightWELD XC provides additional functionality of pre- and post-weld cleaning with the same high-quality welding capabilities of the LightWELD 1500 system.





Welding Capacity

Steel: Stainless Steel, Mild Steel, Galvanized Steel up to 4 mm (0.160")

Aluminum: Aluminum (3XXX & 5XXX Series) up to 4 mm (0.160")

Aluminum:  ---

Titanium & Nickel Alloy:  ---

Copper:  ---

Wobble Welding: Up to 5 mm (0.200") width

Cleaning Scan Width: Up to 15 mm (0.590")

High Frequency Peak Power for Cleaning: 2500 W

Wire Welding Capability: Yes


LightWELD 1500

The most cost-effective solution for laser welding steel, stainless steel, and aluminum up to .160"(4 mm) thick. LightWELD 1500 can be paired with a wire feeder, but does not have any cleaning capability.




Welding Capacity

Steel: Stainless Steel, Mild Steel, Galvanized Steel up to 4 mm (0.160")

Aluminum: Aluminum (3XXX & 5XXX Series) up to 4 mm (0.160")

Aluminum:  ---

Titanium & Nickel Alloy:  ---

Copper:  ---

Wobble Welding: Up to 5 mm (0.200") width

Cleaning Scan Width:  ---

High Frequency Peak Power for Cleaning:  ---

Wire Welding Capability: Yes

Laser power up to 1500 W is easily adjusted with intuitive controls to quickly dial in optimum weld settings for various materials and thicknesses. With 74 stored preset and user-defined process parameters, novice welders can be trained and welding in a matter of hours. Select stored modes provide up to 2500 W of high peak power for even greater welding capability. MWSCO is your LightWELD authorized dealer, sales and service for Iowa, Minnesota, and Wisconsin, in areas including Decorah, Mankato, Red Wing, Rochester, Winona, Altoona, Appleton, Hudson, La Crosse, Madison, Marshfield, and Rothschild.

Unlike traditional methods, welding fixtures are simpler or not needed with LightWELD. Metals do not need to be pre-brushed or ground completely clean, and even novices can reliably weld materials with dissimilar thicknesses and high/low electrical conductivity. LightWELD welds dissimilar metals of different thicknesses with ease and creates aesthetic high-strength joints with minimal or no consumable wire.
